Khoom Taw Qhia
Stainless hlau bellows expansion pob qij txha yog ib hom kev them nyiaj uas feem ntau hu ua bellows sib koom lossis expansion sib koom ua ke. Lub luag haujlwm tseem ceeb ntawm cov khoom no yog los them nyiaj rau thermal expansion thiab contraction displacement uas feem ntau tshwm sim hauv cov kav dej lossis cov khoom siv vim qhov kub thiab txias. Raws li lub hauv caug sib koom ua ke yog ib qho khoom siv elastic, nws tuaj yeem tswj tau qee qhov kev ua haujlwm siab ib yam.
Lub flange square yog ib qho flange uas muaj peev xwm los txhawb kev siab dua li cov rods tuaj yeem ncaj qha rau ntawm plaub fab ntawm flange. Lub Stainless Bellows nrog Square Flange feem ntau yog siv rau hauv kev kub siab thiab kub siab.
Cov khoom no feem ntau yog ua los ntawm cov hlau xws li stainless hlau. Nws lub luag haujlwm tseem ceeb yog muab kev hloov pauv siab thiab kev ntseeg siab hauv cov kav dej. Cov hauv qab no muaj cov txheej sab hauv du thiab qhov chaw tiv thaiv corrosion uas tso cai rau cov kua dej ntws zoo dua. Lub elasticity thiab saj zawg zog ntawm lub hauv caug pab kom nqus tau siab thaum lub sij hawm txias thiab cua sov, thaum tseem txo cov qaug zog thiab tawg.
Khoom parameters
|
Txoj kab uas hla Tsis muaj. |
P×H (mm) |
Ntev (mm) |
Axial Mov. |
Laternal Defl. |
Angular Kev sib hloov |
|
50A |
10×12 |
240 |
12 |
5.5 |
20.2 |
|
65A |
10×12 |
250 |
12 |
16.5 |
16.5 |
|
80A |
10×16 |
250 / 340 |
12 / 15 |
3.9 / 15.8 |
14.1 / 28.1 |
|
100A |
23×24 |
250 / 360 |
12 / 15 |
3.3 / 13.0 |
11.8 / 23.6 |
|
125A |
20×26 |
300 / 440 |
12 / 15 |
3.1 / 12.5 |
10.8 / 22.3 |
|
150A |
35×35 |
300 / 440 |
15 / 30 |
4.0 / 15.9 |
9.9 / 19.9 |
|
200A |
45×38 |
300 / 440 |
16 / 32 |
2.6 / 10.7 |
7.6 / 15.3 |
|
250A |
45×42 |
300 / 440 |
18 / 32 |
2.9 / 8.8 |
7.1 / 12.4 |
|
300A |
50×50 |
300 / 440 / 524 |
18 / 30 / 42 |
2.3 / 6.5 / 12.4 |
6.0 / 9.9 / 13.9 |
|
350A |
50×50 |
300 / 440 / 524 |
23 / 37 / 45 |
2.9 / 8.0 / 11.6 |
6.6 / 11.1 / 13.3 |
|
400A |
50×50 |
300 / 475 / 545 |
23 / 37 / 45 |
2.6 / 7.1 / 10.3 |
9.8 / 11.8 / 5.1 |
|
450A |
50×50 |
300 / 475 / 545 |
23 / 37 / 45 |
2.2 / 6.1 / 8.8 |
8.4 / 10.1 / 4.8 |
|
500A |
50×50 |
300 / 475 / 545 |
23 / 37 / 45 |
2.1 / 5.8 / 8.4 |
8.0 / 9.6 / 2.8 |
|
600A |
60×60 |
300 / 475 / 545 |
16 / 40 / 49 |
1.0 / 6.0 / 8.7 |
7.0 / 8.3 / 2.4 |
|
700A |
60×60 |
300 / 475 / 545 |
16 / 40 / 48 |
0.8 / 5.2 / 7.5 |
2.0 / 7.2 / 3.2 |
|
800A |
60×60 |
400 / 580 / 600 |
24 / 40 / 48 |
1.6 / 4.5 / 6.6 |
5.3 / 7.4 / 2.9 |
Qhov zoo
1. qhov flexural txhav thiab axial rigidity ntawm lub hauv siab sib koom ua ke yog qis dua li cov kav dej uas nyob ib sab, uas ua rau nws muaj kev xaiv zoo dua los txo cov khoom tsim tawm ntawm cov kav dej uas nyob ib sab.
2.cov khoom no tuaj yeem tiv nrog ntau txoj kev xaav, uas ua rau nws hloov tau ntau yam ntawm cov kav dej.
3.Qhov tsim ntawm cov khoom no yog qhov yooj yim thiab compact, uas ua rau nws yooj yim rau nruab thiab tswj.
4.the Stainless Bellows nrog Square Flange muaj lub neej ua haujlwm ntev raws li nws tiv taus corrosion, kev co thiab qaug zog puas tsuaj, nrog rau kev hloov siab.
Zuag qhia tag nrho, stainless hlau bellows expansion pob qij txha yog ib yam khoom uas muaj ntau yam, ruaj thiab txhim khu kev qha khoom uas yog ib qho tseem ceeb nyob rau hauv ntau lub siab kub thiab kub pipeline systems. Nws lub peev xwm los nqus kev co, axial thiab lateral txav thiab siab hloov pauv ua rau nws yog qhov kev xaiv zoo tshaj plaws rau ntau yam kev lag luam.
